| Stock Number (在庫番号) | X201 |
| Manufacturer (メーカー) | OKUMA |
| Model (型式) | MCV-AII |
| Year (年式) | 2001 |
| Machine Name (機械名) | MACHINING CENTER |
| Specifications / Others (仕様・その他) | Spindle speed: 4,000min -1 (special specifications: 6,000min -1 , 10,000min -1 ) Spindle motor: 22/18.5kW Rapid forward speed (X/Y axis): 20m/min Cutting feed speed: max 10,000mm/min Large diameter spindle quill: ø210mm Z-axis stroke: 450mm |
| Specification | Details |
|---|---|
| Machine Type | Vertical Machining Center (VMC) |
| Manufacturer | OKUMA, Japan |
| Model | MCV-AII |
| Year of Manufacture | 2001 |
| Table Size | ~2000 x 800 mm |
| Table Load Capacity | ~2,000 kg |
| X-Axis Travel | ~2,000 mm |
| Y-Axis Travel | ~800 mm |
| Z-Axis Travel | ~700 mm |
| Spindle Taper | BT50 |
| Spindle Speed | 30 – 6,000 RPM |
| Spindle Motor Power | ~15 – 22 kW |
| Tool Magazine Capacity | 32 – 60 Tools |
| Controller | OKUMA OSP-E100M / OSP-U100M |
| Weight | 21500 kg |
|---|
