Capacities:
- Swing Over Bed: ø460 mm (approximately 18.1 inches)
- Swing Over Cross Slide: ø250 mm (approximately 9.8 inches)
- Maximum Turning Length: 1500 mm
- Spindle Bore: ø52 mm (approximately 2 inches)
- Chuck Size: 10-inch, 3-jaw chuck.
Spindle:
- Spindle Speed Range: Typically 25 – 1500 min⁻¹ (rpm), with 12 speed changes.
- Spindle Nose: Usually A1-6″ type.
- Spindle Motor Power: Typically 3.7 kW (5 HP) or optionally 5.5 kW (7.5 HP).
